Objects Session Notes
NGC 6058 - Planetary Nebula Abell 82 - Planetary Nebula (PLN 114- 4.1) Abell 39 - Planetary Nebula (PLN 47+42.1) Jones 1 - Planetary Nebula (PK 104-29.1) Abell 70 - Planetary Nebula (PK 38-25.1) NGC 1 - Spiral Galaxy NGC 7000 - Nebula ("North America nebula") M101 - spiral galaxy with supernova 2011fe Variable Stars Photometric Monitoring - Variables - U And, W And, Z And, TT Ari, R CrB, CI Cyg, SS Cyg, U Her, BL Lac, DY Per, GK Per, FG Sge, U Sge, V Sge, WZ Sge
Astrometric Monitoring - Nearby Stars - Barnard's Star, 61 Cyg, Groombridge 34, And, EV Lac, Teegardens Star
- Evening session (6.0 hrs duration).
Good conditions- Session operated under semi-automated control, with remote monitoring from indoors computer.
Successful first use of Power-Line networking (no drops out for whole of session)- Ambient Temperature: -3.0 deg C (minimum)
Dew/Frost requiring corrector plate to be cleared with hair dyer on 3-4 occasions.- CCD operation -25 degC (at 55% average cooling). - main objectives of the session were to acquire images of selected project stars for ongoing photometric and astrometric analysis, and to image a number of planetary nebula -
| NGC 6058 (Hercules) |
|
|
CCD Image (cropped) 3 x 45s sec exposure (average combine), 2x2 binning, C Filter 2012-10-15 19:40 h UT (#515094-96) 12" LX200R (at f/9.7) + ST-10XME |
| NGC 6058 - earlier attempt (2012-10-10) |
|
|
CCD Image (cropped) 3 x 20s sec exposure (average combine), 3x3 binning, C Filter 2012-10-10 21:32 h UT (#514026-28) 12" LX200R (at f/9.7) + ST-10XME |
Back to Top
| Abell 82 / PLN 114- 4.1 (Cassiopeia) |
|
|
CCD Image (50%, ) 3 x 45s sec exposure (average combine), 3x3 binning, C Filter 2012-10-15 21:18 h UT (#515119-21) 12" LX200R (at f/9.7) + ST-10XME |
| Abell 82 - detail |
|
|
Negative CCD Image (Gamma adjusted)
Image details as above |
Back to Top
| Abell 39 / PLN 47+42.1 (Hercules) |
|
|
CCD Image (slight smoothed, 50%, ) 8 x 90s sec exposure (average combine), 3x3 binning, C Filter 2012-10-15 21:18 h UT (#515213-20) 12" LX200R (at f/9.7) + ST-10XME [ internet picture showing Abell 39 for reference, by Capella Observatory ] |
|
|
Negative CCD Image (Gamma adjusted)
Image details as above |
| Abell 39 - detail |
|
|
Annotated CCD Image (80% size, cropped) Image details as above |
| Earlier attempt to imaging Abell 39 / PLN 47+42.1
(2012-10-10) Planetary Nebula (expected extent shown by grey circle) is not visible in this 20s image taken under poor quality skies Central star is just visible |
|
|
CCD Image (50% size) 20s sec exposure (single frame), 3x3 binning, C Filter 2012-10-10 21:09 h UT (#514035) 12" LX200R (at f/9.7) + ST-10XME |
Back to Top
|
Jones 1 / PK 104-29.1 (Pegasus) |
 |
| CCD Image (60% size, cropped) 9 x 90s exposure (average combine), 3x3 binning, C Filter 2010-10-15 22:07 hUT (#515268-76) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
Jones 1 - earlier image ( 2010-08-20) |
 |
| CCD Image (60% size, cropped) 6 x 90s exposure (average combine), 3x3 binning, C Filter 2010-08-20 22:35 hUT (#424026-34) 12" LX200R (at f/9.7) + ST-10XME |
Back to Top
| Abell 70 / PK 38-25.1 (Aquila) |
|
|
CCD Image (cropped) 6 x 90s sec exposure (average combine), 3x3 binning, C Filter 2012-10-15 22:26 h UT (#515281-89) 12" LX200R (at f/9.7) + ST-10XME |
| Abell 70 - detail |
|
|
Negative CCD Image (cropped, gamma adjusted)
Image details as above |
Back to Top
| NGC 1 & NGC 2 (Pegasus) |
|
|
Annotated CCD Image (cropped) 5 x 90s sec exposure (average combine), 3x3 binning, C Filter 2012-10-15 22:41 h UT (#515292-96) 12" LX200R (at f/9.7) + ST-10XME |
Back to Top
|
Part of NGC 7000 (Cygnus) |
|
|
|
LRGB CCD Image (50% size) L : 5 x 90s exposure, Ha filter R: 90s, R Filter / G: 90s, V Filter / B : 90s, B filter 3x3 binning 2012-10-16 00:03 h UT (#515377-85) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
Part of NGC 7000 in Ha |
|
|
|
H-alpha CCD Image (50% size) 5 x 90s exposure, 3x3 binning, Ha filter 2012-10-16 00:03 h UT (#515377-85) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
|
|
False Colour H-alpha CCD Image (50% size) Image details as above |
|
|
|
Part of NGC 7000 - detail |
|
|
|
H-alpha CCD Image (cropped) Image details as above |
|
|
|
A second part of NGC 7000 |
|
|
|
False Colour CCD Image (cropped) R :: 3 x 90s, 3x3 binning, Ha filter G & B:: 3 x 20s, 3x3 binning, C filter 2012-10-15 23:42 h UT (#515362-67) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
Earlier Image of Southern Part of NGC 7000 (2006-12-08) |
|
|
|
CCD Image Mosaic- 4x4 frames (50% size) 180s exposure, 2x2 binning, C filter, Linear scale. Slight Smoothing 2006-12-08 19:10h UT (#160077-92) [larger image, 75% size] |
Back to Top
|
M101 with supernova 2011fe (Ursa
Major) |
SN 2011fe is reported as being the nearest Type 1a supernova seen in decades |
|
| Images of M101 with supernova 2011fe | ||
 |
New Image (+414d) 2012-10-15 419 days after SN discovery SN Est. Mag only just visible, ~ 17.2 Annotated CCD Image (58% size, cropped) 10 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-10-15 19:49 h UT (#515124-33) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+414d) 2012-10-10 414 days after SN discovery SN Est. Mag not visible, > 17.2 Annotated CCD Image (58% size, cropped) 7 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-10-10 21:24 h UT (#514050-58) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+346d) 2012-08-03 346 days after SN discovery SN Est. Mag +16.5 Annotated CCD Image (58% size, cropped) 5 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-08-03 22:26 h UT (#512215-19) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+249d) 2012-04-28 249 days after SN discovery SN Est. Mag +15.4 Annotated CCD Image (58% size, cropped) 10 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-04-28 22:12 h UT (#511114-23) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+238d) 2012-03-26 238 days after SN discovery SN Est. Mag +15.3 Annotated CCD Image (58% size, cropped) 10 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-04-17 22:41 h UT (#510084-93) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+216d) 2012-03-26 216 days after SN discovery SN Est. Mag +15.0 Annotated CCD Image (58% size, cropped) 11 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-03-26 22:42 h UT (#507066-74) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+164d) 2012-02-03 164 days after SN discovery SN Est. Mag +14.1 Annotated CCD Image (58% size, cropped) 8 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-02-03 22:55 h UT (#500113-20) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+157d) 2012-01-28 157 days after SN discovery SN Est. Mag +14.0 Annotated CCD Image (58% size, cropped) 7 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-01-28 00:28 h UT (#499122-31) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+146d) 2012-01-16 146 days after SN discovery SN Est. Mag +13.8 Annotated CCD Image (58% size, cropped) 9 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-01-16 20:38 h UT (#497140-48) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+131d) 2012-01-01 131 days after SN discovery SN Est. Mag +13.4 Annotated CCD Image (58% size, cropped) 6 x 60 sec exposure (average combine), 3x3 binning, C Filter 2012-01-01 23:46 h UT (#494143-51) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+114d) 2011-12-15.78 114 days after SN discovery SN Est. Mag +13.1 Annotated CCD Image (58% size, cropped) 8 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-12-15 18:43 h UT (#490110-19) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+96d) 2011-11-27.84 96 days after SN discovery SN Est. Mag +12.6 Annotated CCD Image (58% size, cropped) 8 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-11-27 20:11 h UT (#488012-20) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+90d) 2011-11-21.84 90 days after SN discovery SN Est. Mag +12.5 Annotated CCD Image (58% size, cropped) 11 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-11-21 20:10 h UT (#486016-26) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+75d) 2011-11-06.90 75 days after SN discovery SN Est. Mag +12.1 Annotated CCD Image (58% size, cropped) 10 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-11-06 21:32 h UT (#483004-14) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+70d) 2011-11-01.85 70 days after SN discovery SN Est. Mag +11.9 Annotated CCD Image (58% size, cropped) 12 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-11-01 19:13 h UT (#482011-22) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+65d) 2011-10-27.85 65 days after SN discovery SN Est. Mag +11.7 Annotated CCD Image (58% size, cropped) 12 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-10-27 20:20 h UT (#481008-19) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+54d) 2011-10-16.83 54 days after SN discovery SN Est. Mag +11.2 Annotated CCD Image (58% size, cropped) 7 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-10-16 20:00 h UT (#480169-78) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+41d) 2011-10-03.85 41 days after SN discovery SN Est. Mag +10.5 Annotated CCD Image (58% size, cropped) 11 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-10-03 20:28 h UT (#479003-14) 12" LX200R (at f/9.7) + ST-10XME |
|
|
|
||
 |
Earlier Image (+37d) 2011-09-29.88 37 days after SN discovery SN Est. Mag ~ +11.1 Annotated CCD Image (58% size, cropped) 4 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-09-29 21:04 h UT (#478008-11) 12" LX200R (at f/9.7) + ST-10XME Note : Poor sky transparency + frost on edges of CCD |
|
|
|
||
 |
Earlier Image (+1.9d) 2011-08-25.91 ~ 1.9 days after SN discovery SN Est. Mag +13.4 Annotated CCD Image (58% size, cropped) 9 x 60 sec exposure (average combine), 3x3 binning, C Filter 2011-08-25 21:41 h UT (#477019-28) 12" LX200R (at f/9.7) + ST-10XME |
|
 |
Earlier Image (pre-discovery) 2009 CCD Image (cropped) 9 x 60 sec (average combine), 3x3 binning, C Filter 2009-08-24 22:00 h UT (#386001-10) 12" LX200R (at f/5.7) + ST-10XME |
|
| SN 2011fe Light Curve | ||
 |
||
