David's Astronomy - Images 2009-09-19 (S00389)

Objects Session Notes

C/2006 W3 (Christensen) - Comet

IC 10 - Spiral Galaxy (Local Group)

IC 1525 - Spiral Galaxy

P Cyg - Star

22/P Kopff - Comet

M57 - Planetary Nebula

PGC 54 - Galaxy Group (Hickson 99)

AE And - variable star in M31

HY And - variable star in M31

AF And - variable star in M31

M110 - Elliptical Galaxy (Local Group)

M32 - Elliptical Galaxy (Local Group)

NGC 253 - Spiral Galaxy (Caldwell 65)

NGC 288 - Globular Cluster

NGC 247 - Spiral Galaxy (Caldwell 62)

NGC 246 - Planetary Nebula (Caldwell 56)

M74 - Spiral Galaxy

M77 - Spiral Galaxy

136199 Eris - Dwarf Planet (2003 UB313)

Satellite or plane

NGC 404 - Elliptical Galaxy (Mirach's Ghost)

M1 - Supernova remnant (Crab Nebula)

CM Tau - Pulsar Star in M1

Photometric Monitoring - Variables

- RX And, U And, W And, Z And, TT Ari, HR Aur,
- KR Au, R CrB, AM CVn, CI Cyg, SS Cyg, U Her,
- BL Lac, CY Lyr, CN Ori, FO Ori, FU Ori, NV Ori,
- DY Per, GK Per, FG Sge, U Sge, V Sge,
- RR Tau, ER UMa, SU UMa

Photometric Monitoring - Nearby Stars

- Barnards Star, Gliese 412, Groombridge 1830, Groombridge 34, Ross 248 (HH And), EV Lac

- All night session (8.9 hr).

- Operated under automated control with remote monitoring.

- Ambient Temperature 10 deg C (minimum), rising to 11 deg.

- CCD operation -20 degC (at 58% average cooling).

- main objective of the session was to acquire images of key selected stars for ongoing photometric and astrometric analysis.

- secondary objective of the session became the acquisition of images from a number of deep sky targets including Caldwell 56, 62 & 65

- Notes from 2009-09-19

C/2006 W3 (Christensen)
passing through star field in Aquila

CCD Image (cropped to central area)
3 x 30s sec exposure (average combine), 3x3 binning, C Filter
2009-09-19 20:48 h UT (#389071-73)
12" LX200R (at f/5.7) + ST-10XME

IC 10 (Cassiopeia)

CCD Image (50% size, Linear Scale)
5 x 90 sec (average combine), 3x3 binning, C Filter
2009-09-19 21:05 h UT (#389076-80)
12" LX200R (at f/5.7) + ST-10XME

IC 10

False Colour CCD Image (50% size, Log Scale)
Image details as above

IC 10 - detail

False Colour CCD Image (Cropped to Central Area, Square Root Scale)
Image details as above

False Colour CCD Image (Cropped to Central Area, Log Scale)
Image details as above

IC 1525 (Andromeda)

Annotated CCD Image (cropped, linear scale)
90 sec exposure, 3x3 binning, C Filter
2009-09-19 21:45 h UT (#389138)
12" LX200R (at f/5.7) + ST-10XME

IC 1525 - detail

CCD Image (200% size, cropped, linear scale)
Image details as above

P Cyg (Cygnus)

CCD Image
3 x 3 sec (average combine), 1x1 binning, C Filter
2009-09-19 22:11 h UT (#389172-74)
12" LX200R (at f/5.7) + ST-10XME

Earlier Spectra of P Cyg (2008)

CCD Spectra
3 x 10s
2008-05-08 01:16hUT
(#286177-79)
8" LX200 + ST-7e

22/P Kopff
passing through star field in Aquarius

CCD Image (cropped to central area)
3 x 20s sec exposure (average combine), 3x3 binning, C Filter
2009-09-19 22:34 h UT (#389210-12)
12" LX200R (at f/5.7) + ST-10XME

M57 (Lyra)

CCD Image
15 x 20 sec (average combine), 3x3 binning, C Filter
2009-09-19 22:40 h UT (#389215-29)
Unsharp Masked
12" LX200R (at f/5.7) + ST-10XME

Hickson 99 and surrounding starfield (Pegasus)
Image of Hickson 99 & surrounding starfield with numerous faint galaxies
Limiting magnitude +18.7
Bright star is HIP 121 (mag +6.8)

CCD Image (75% scale)
9 x 30 sec (average combine), 3x3 binning, C Filter
2009-09-19 23:46 h UT (#389308-15)
12" LX200R (at f/5.7) + ST-10XME
[Negative, 100% size]

Hickson 99 - galaxy group
Distance ~ 460 million light years

CCD Image (cropped to central area)
Image details as above

Hickson 99 - detail
PGC 54 - Edge on Spiral Galaxy (catalog mag +14.8)
PGC 58 - Face on Spiral Galaxy (catalog mag +15.6)
PGC 63 - Elliptical Galaxy (catalog mag + 14.7)
PGC 60 (catalog mag +17.1), PGC 57 (catalog mag +17.6)

Annotated CCD Image
(200% size, cropped to central area)
Image details as above

AE And (Andromeda)
GCVS catalog data :
Type: SDOR. Range: +15.1 to +17.6
Alt. designation M31 V1005
Est. Mag in image below +16.3

Annotated CCD Image (cropped)
3 x 90 sec (average combine), 2x2 binning, C Filter
2009-09-19 23:59 h UT (#389333-35)
12" LX200R (at f/5.7) + ST-10XME

AE And and HY And in M31
Satellite track caught in one of 3 frames

CCD Image (35% size, full frame)
Image details as above
[ 100% size ]

CCD Image (75% size, cropped)
Image details as above

HY And (Andromeda)
GCVS catalog data :
Type: UV. Range: +18.2 to +20
Alt. designation M31 V0830
Est. Mag in image below +17.5

Annotated CCD Image (cropped)
3 x 90 sec (average combine), 2x2 binning, C Filter
2009-09-19 23:59 h UT (#389333-35)
12" LX200R (at f/5.7) + ST-10XME

AF And (M31, Andromeda)

Annotated CCD Image (Linear Scale, Cropped)
3 x 90 sec (average combine), 2x2 binning, C Filter
2009-09-20 00:08 h UT (#389338-40)
12" LX200R (at f/5.7) + ST-10XME

M31 - part (Andromeda)
centered on AF And

CCD Image (35% size, Full Frame)
3 x 90 sec (average combine), 2x2 binning, C Filter
2009-09-20 00:08 h UT (#389338-40)
Log Scale,
12" LX200R (at f/5.7) + ST-10XME

M31 - detail

False colour CCD Image (35% size, Full Frame)
Log Scale - Inverse Spectrum
Image details as above

M110 (Andromeda)
Elliptical Galaxy
Irregular dark dust clouds noted near nucleus

CCD Image (Linear Scale, Cropped)
5 x 60 sec (average combine), 3x3 binning, C Filter
2009-09-20 00:14 h UT (#389343-47)
12" LX200R (at f/5.7) + ST-10XME

M32 (Andromeda)
Elliptical Galaxy
almost devoid of features apart from central condensation

CCD Image (Linear Scale, 50% size)
5 x 60 sec (average combine), 3x3 binning, C Filter
2009-09-20 00:23 h UT (#389351-55)
12" LX200R (at f/5.7) + ST-10XME

M32 - detail

False Colour CCD Image (Log Scale, 50% size)
Image details as above

NGC 253 / Caldwell 65 / Herschel I-5 (Sculptor)
Declination -25 deg. Taken whilst at altitude of 7 deg (airmass 7.6)
Also known at the Silver Coin Galaxy

Annotated CCD Image (Linear scale, 50% size)
17 x 60 sec exposure, 3x3 binning, C Filter
2009-09-20 21:45 h UT (#389358-74)
12" LX200R (at f/5.7) + ST-10XME

NGC 253 - detail

CCD Image (200% size, cropped, linear scale)
Image details as above

NGC 288 / Herschel VI-20 (Sculptor)
Declination -26 deg. Taken whilst at altitude of 6 deg

CCD Image (Linear scale, 75% size, cropped)
8 x 30 sec exposure, 3x3 binning, C Filter
2009-09-20 00:51 h UT (#389377-81, 38900-02)
12" LX200R (at f/5.7) + ST-10XME

NGC 247 / Caldwell 62 / Herschel V-20 (Cetus)

Annotated CCD Image (Linear scale, 50% size)
10 x 60 sec exposure, 3x3 binning, C Filter
2009-09-20 01:31 h UT (#389410-19)
12" LX200R (at f/5.7) + ST-10XME

NGC 246 / Caldwell 56 / Herschel V-25 (Cetus)

Annotated CCD Image (Linear scale, cropped)
10 x 60 sec exposure, 3x3 binning, C Filter
2009-09-20 01:46 h UT (#389421-30)
12" LX200R (at f/5.7) + ST-10XME

M74 (Pisces)

CCD Image (Linear Scale, 50% size)
7 x 60 sec (average median combine), 3x3 binning, C Filter
2009-09-20 01:59 h UT (#389434-40)
12" LX200R (at f/5.7) + ST-10XME

M74 - face on spiral galaxy

CCD Image (Linear Scale, cropped)
Image details as above

M74 - detail

CCD Image (Square Root Scale, cropped)
Image details as above

False Colour CCD Image (Square Root Scale, cropped)
Inverse Spectrum
Image details as above

M77 (Cetus)

CCD Image (Linear Scale, 50% size)
10 x 60 sec (average combine), 3x3 binning, C Filter
2009-09-20 02:10 h UT (#389443-52)
12" LX200R (at f/5.7) + ST-10XME

M77 - face on spiral galaxy
with diffuse outer arms

CCD Image (Square root scaling, cropped)
Image details as above

M77 - inner arms detail

CCD Image (Log Scale, 200% size, cropped)
Unsharp masked
Image details as above

M77 - outer arms detail

False Colour CCD Image (Square Root Scale, cropped)
Inverse Spectrum
Image details as above

Dwarf Planet (136199) Eris Observation of Eris on 2009-09-20, lying in starfield in Cetus Faint object marked by cross-hairs lies at the forecast position of Eris on 2009-09-20 has approximately the correct magnitude (+18.3 measured vs. +18.7 predicted) and is not present on a DSS Reference Image, or on image taken 18 days later. Eris is the largest known object in the Kuiper Belt with estimated diameter of 2,500 km (it was previously known at 2003 UB313) The bright star in the image is HIP 7802 (mag +8.8)

Annotated CCD Image (cropped) 18 x 60 sec (average median combine), 3x3 binning, C Filter 2009-09-20 00:08 h UT (#389461-80) 12" LX200R (at f/5.7) + ST-10XME


Negative CCD Image (cropped) Image details as above

136199 Eris - higher contrast image (sum combined)

Negative CCD Image (cropped) 18 x 60 sec (sum combine), 3x3 binning, C Filter 2009-09-20 00:08 h UT (#389461-80) 12" LX200R (at f/5.7) + ST-10XME


DSS Reference Image Reference image for same area doesn't show any object at the precise location of suspect dwarf planet Eris. There are two nearby very faint objects but these are sufficiently far away and are just about recognised in my images on 2009-09-20. (see side by side comparison below) [ http://archive.eso.org/dss/dss ] (DSS-2-Red image / object HIP 7802)

DSS-2-Red Reference Image (Negative)

136199 Eris - Image Detail (2009-09-20)		DSS Reference Image

CCD Image (237% size, Negative, Cropped) 18 x 60 sec (sum combine), 3x3 binning, C Filter 2009-09-20 00:08 h UT (#389461-80) 12" LX200R (at f/5.7) + ST-10XME		Reference Image (Negative, Cropped) DSS-2-Red Survey [ http://archive.eso.org/dss/dss ]


136199 Eris - Image Detail (2009-09-20)		Later Image of same area (2009-10-08)

CCD Image (237% size, Negative, Cropped) 18 x 60 sec (sum combine), 3x3 binning, C Filter 2009-09-20 00:08 h UT (#389461-80) 12" LX200R (at f/5.7) + ST-10XME		CCD Image (237% size, Negative, Cropped) 30 x 60 sec (average combine), 3x3 binning, C Filter 2009-10-08 00:11 h UT (#392459-88) 12" LX200R (at f/5.7) + ST-10XME



MPL 2003 UB313 earlier observation attempt taken 2 nights before (2009-09-18) Note : absence of any object the position of the later suspected object.

Expected position of Eris on 2009-09-18 is indicated by the black circle. With predicted magnitude of 18.7, Eris is probably too faint to seen in this image (mag limit +18), and in any case would also almost certainly be lost in the glare from the adjacent mag +8.8 star. Note : the absence of any star object at the position of suspected object two days later. However this is not definitive evidence since the magnitude limit of the image is not quite sufficiently deep. It can be seen that there are a number of other objects (star/faint galaxies) which can be seen in the 2009-09-20 image but not in the earlier 2009-09-18 image.
Annotated CCD Image (cropped to central area) 12 x 60 sec (average combine), 3x3 binning, C Filter 2009-09-18 00:08 h UT (#388100-12) 12" LX200R (at f/5.7) + ST-10XME

Spinning/Flaring Satellite or Plane with Flashing Light passing across starfield in Cetus

CCD Image (Linear Scale)
2 x 60 sec (sum combine), 3x3 binning, C Filter
2009-09-20 02:40 h UT (#389472-73)
12" LX200R (at f/5.7) + ST-10XME

NGC 404 / Herschel II-224 (Andromeda)
Spheroid Galaxy close to Mirach (mag +2)
It lies around 10.3 million light years away, just outside the Local Group

CCD Image (Linear Scale, cropped)
7 x 20 sec (average combine), 3x3 binning, C Filter
2009-09-20 03:00 h UT (#389493-99)
12" LX200R (at f/5.7) + ST-10XME

NGC 404 - detail
black strip is blooming spike from Mirach.

Negative CCD Image (200% size, cropped)
Image details as above

M1 (Taurus)

CCD Image (Linear Scale, 50% size)
5 x 60 sec (average combine), 3x3 binning, C Filter
2009-09-20 03:45 h UT (#389568-72)
12" LX200R (at f/5.7) + ST-10XME

CCD Image (Linear Scale, cropped)
Image details as above

M1 - detail

CCD Image (Linear Scale, 100% size, cropped)
20 x 30 sec (average combine), 1x1 binning, C Filter
2009-09-20 03:51 h UT (#389584-61)
12" LX200R (at f/5.7) + ST-10XME

False Colour CCD Image (100% size, cropped)
Image details as above

M1 with CM Tau Pulsar Star at centre (Taurus)

CCD Image (Linear Scale, 100% size, cropped) 20 x 30 sec (average combine), 1x1 binning, C Filter 2009-09-20 03:51 h UT (#389584-61) 12" LX200R (at f/5.7) + ST-10XME

CM Tau - pulsar star at centre of M1

CCD Image (Linear Scale, cropped) image details as above

CM Tau - single frame taken from dataset of 20 best frames

CCD Image (Linear Scale, cropped) 30 sec, 1x1 binning, C Filter 2009-09-20 03:51 h UT (#389597) 12" LX200R (at f/5.7) + ST-10XME

CM Tau - 35 frames (including both good & bad frames)		CM Tau - 35 frames (best frames only)

CCD Image Animation (35 frames) 30 sec frames, 1x1 binning, C Filter 2009-09-20 03:51 h UT (#389584-618)		CCD Image Animation (20 frames) 30 sec frames, 1x1 binning, C Filter 2009-09-20 03:51 h UT (#389584-618)

CM Tau - Average of 7 frames

CCD Image (Linear Scale, cropped) 7 x 30 sec (average combine), 1x1 binning, C Filter 2009-09-20 03:51 h UT (#389584-98) 12" LX200R (at f/5.7) + ST-10XME

This Web Page:	CCD Images - Session 389 (2009-09-19)
Last Updated :	2015-05-16

David's Astronomy Pages
CCD Images - Session 389 (2009-09-19)

C/2006 W3 (Christensen) - Comet

IC 10 - Spiral Galaxy (Local Group)

IC 1525 - Spiral Galaxy

P Cyg - LBV Star

22/P Kopff - Comet

M57 - Planetary Nebula

PGC 54 - Galaxy Group (Hickson 99)

AE And - Variable Star in M31

HY And - Variable Star in M31

AF And - Variable Star in M31

M110 - Elliptical Galaxy (Local Group)

M32 - Elliptical Galaxy (Local Group)

NGC 253 - Spiral Galaxy (Caldwell 65)

NGC 288 - Globular Cluster

NGC 247 - Spiral Galaxy (Caldwell 62)

NGC 246 - Planetary Nebula (Caldwell 56) "Skull Nebula"

M74 - Spiral Galaxy

M77 - Spiral Galaxy

136199 Eris - Dwarf Planet (2003 UB313)

Satellite or plane

NGC 404 - Elliptical Galaxy (Mirach's Ghost)

M1 - Supernova remnant (Crab Nebula)

CM Tau - Pulsar Star in M1

David's Astronomy Pages CCD Images - Session 389 (2009-09-19)
