CCD Session S00084 Notes from CCD Session Jupiter Saturn
- 2.5 hour imaging session in which the main aim was to record colour images of Jupiter and Saturn
Back to Top
| Jupiter with Red Spot prominent |
|
|
CCD Colour Image Exposures : Red 0.11s, Green 0.11s, Blue 0.2s Processing: Unsharp Masked, Aligned, and Colour Combined 8" LX200 operating at f/10.3 2005-04-06 21:56 h UT (#84103-05) |
| Jupiter (alternative colour balance) |
|
|
CCD Colour Image Exposures : Red 0.11s, Green 0.11s, Blue 0.2s Processing: Unsharp Masked, Aligned, and Colour Combined 8" LX200 operating at f/10.3 2005-04-06 22:00 h UT (#84131-33) |
| Jupiter |

|
|
CCD Colour Images (as above) |
|
|
CCD Image Red Filter 8 x 0.15s summed, unsharp masked. 2005-04-06 22:11 h UT (#84191-215) |
|
| Jupiter & Moons |
|
|
CCD Image 0.5 sec exposure, clear filter 2005-04-06 21:28 h UT (#84015) |
Back to Top
| Saturn |
|
|
CCD Image 5 x 0.4sec (summed), Red Filter LX200 with barlow, operating at f/23 2005-04-06 23:31h UT (#84339-51) |
| Saturn |
|
|
CCD Image 9 x 3sec (summed), Red Filter, Unsharp Masked 2005-04-06 23:40h UT (#84379-87) |
| Saturn Moons |
|
|
CCD Colour Image 5 x 0.5s (sum combine), RGB Filters 2005-04-06 23:31h UT (#84339-53) |
