Notes (S00068)

- Imaging session was with a focal reducer bringing 8" f/10 LX200 to f/7.
- Images were recorded with ST7 CCD camera.  Filter Wheel with CBVRI filters
- Seeing was moderate, but cloud gradually built up through session.
- 2.5 hour session

Back to Top

C/2001 HT50 - Comet

C/2001 HT50

CCD  Image, 3 x 60 sec exposure, C filter 2004-08-22  22:08h UT (#68053-55)

Back to Top

M76 (Little Dumbbell)- Planetary Nebula

M76 (Perseus)

CCD  Image, 7 x 60 sec exposure (average combine) Clear Filter 2004-08-22  23:15 h UT (#68129+)

M76 (False-Colour Display)

False Colour CCD  Image (Logarithmic Scaling, Spectrum Colour Scale) 7 x 60 sec exposure (average combine) Clear Filter 2004-08-22  23:15 h UT (#68129+)

M76 through CBVRI Filters

CCD  Animation,  C  (4x60s), B (2x120s), V (2x60s), R(2x60s), I (2x60s) 2004-08-22  23:02 to 23:23 h UT (#68125-43)

M76 Colour Image

CCD  Approximate Colour Image  Constructed by taking R (2x60s) as Red,  V(2x60) as Green,  B (2x120s) as Blue  2004-08-22  23:02 to 23:23 h UT (#68125-43)

M76 Colour Image

CCD  Colour Image  Constructed by taking R (2x60s) as Red, V(2x60) as Green,   B (2x120s) as Blue and C (4x60s) as Luminance 2004-08-22  23:02 to 23:23 h UT (#68125-43)

M76 False Colour Image

False Colour CCD  Image  Constructed by taking I (2x60s) as Red, V(2x60) as Green,   B (2x120s) as Blue and R(2x60s) as Luminance 2004-08-22  23:02 to 23:23 h UT (#68125-43)

Back to Top

M31 (Andromeda Galaxy)

Regions of M31 (Andromeda)

CCD  Image, 6x60 sec exposure (average combine) Clear Filter 2004-08-22  23:48 h UT (#68154-62)

CCD  Image, 5x60 sec exposure (average combine) Clear Filter 2004-08-22  23:38 h UT (#68145-52)

Index Image :Showing B/W CCD Images inserted  within a Colour Image of M31 (from TheSky6)

Back to Top

HD 209458 (Osiris) - star to extra-solar planet system

A sequence of images of HD209458 were taken through V and R filters. These will be processed in order to understand the magnitude measurement precision and indicate whether it would be likely to detect dimming in the star associated with transit of its planet.
